Industrial fluid transmission stainless steel pipes are designed to transport fluids in various industrial applications. Made from high-quality stainless steel, they offer exceptional corrosion resistance, strength, and durability. These pipes are commonly used in chemical processing, food and beverage production, and oil and gas industries, ensuring reliable fluid flow.
Quantity
What Is Industrial Fluid Transmission Stainless Steel Pipe?
Stainless steel pipes are commonly used as industrial fluid transmission pipe due to their corrosion resistance and durability. These pipelines are typically used to transport various fluids such as water, chemicals, gases, and other liquids in industrial environments. The smooth inner surface of stainless steel pipes helps maintain the integrity of the conveyed fluid and minimizes the risk of corrosion or contamination.
In addition, stainless steel pipe can withstand high temperatures and pressures, making them suitable for demanding industrial applications. They are also known for their strength and impact resistance, making them a reliable choice for fluid transport systems.
When selecting stainless steel pipe for industrial fluid transportation, it is important to consider factors such as stainless steel grade, pipe size, wall thickness, and end connections to ensure that they meet the specific requirements of the intended application.
304 and 316 are two different grades of stainless steel, commonly used in various applications, including pipelines. Although both grades contain similar basic elements, 316 stainless steel contains additional molybdenum, making it more corrosion-resistant in harsh environments and marine applications.
| Categories | 304 316 Industrial Stainless Steel Pipe, SS Pipe |
| Brand | Youfa Stainless Steel Pipe Manufacturer |
| Diameter | DN15-DN1000 (21mm-1016mm) |
| Material | 304 304L 316 316L |
| Nominal Pipe Sizes | 1/2 inch to 40 inch |
| Thickness | Sch5s, Sch10s, Sch20s, Sch40s |
| Usage | Industrial Fluid Transmission |
| Standards | ASTM A312, ASTM A358, ASTM A790, ASTM A928, JIS G3459,JISG3468,EN10217 |
| FOB port | Tianjin Port, China |
| Terms of Payment | L/C, T/T |
304 316 Industrial Stainless Steel Pipe Product Show
304 316 Industrial Stainless Steel Pipe Specifications
| Nominal | Kg/m Materials:304 (Wall Thickness,Weight) | |||||||||||||
| Pipes Size | OD | Sch5s | Sch10s | Sch20s | Sch40s | |||||||||
| DN | In | mm | In | mm | kg/m | In | mm | Kg/m | In | mm | Kg/m | In | mm | Kg/m |
| DN15 | 1/2’’ | 21.34 | 0.065 | 1.65 | 0.809 | 0.083 | 2.11 | 1.011 | ||||||
| DN20 | 3/4’’ | 26.67 | 0.065 | 1.65 | 1.028 | 0.083 | 2.11 | 1.291 | ||||||
| DN25 | 1’’ | 33.4 | 0.065 | 1.65 | 1.305 | 0.109 | 2.77 | 2.113 | 0.12 | 3.05 | 2.306 | 0.133 | 3.38 | 2.528 |
| DN32 | 1 1/4’’ | 42.16 | 0.065 | 1.65 | 1.665 | 0.109 | 2.77 | 2.718 | 0.12 | 3.05 | 2.971 | 0.14 | 3.56 | 3.423 |
| DN40 | 1 1/2’’ | 48.26 | 0.065 | 1.65 | 1.916 | 0.109 | 2.77 | 3.139 | 0.12 | 3.05 | 3.435 | 0.145 | 3.68 | 4.087 |
| DN50 | 2’’ | 60.33 | 0.065 | 1.65 | 2.412 | 0.109 | 2.77 | 3.972 | 0.12 | 3.05 | 4.352 | 0.145 | 3.91 | 5.495 |
| DN65 | 2 1/2’’ | 73.03 | 0.083 | 2.11 | 3.728 | 0.12 | 3.05 | 5.317 | 0.156 | 3.96 | 6.813 | 0.203 | 5.16 | 8.724 |
| DN80 | 3’’ | 88.9 | 0.083 | 2.11 | 4.562 | 0.12 | 3.05 | 6.522 | 0.156 | 3.96 | 8.379 | 0.216 | 5.49 | 11.407 |
| DN90 | 3 1/2’’ | 101.6 | 0.083 | 2.11 | 5.229 | 0.12 | 3.05 | 7.487 | 0.156 | 3.96 | 9.632 | 0.226 | 5.74 | 13.706 |
| DN100 | 4’’ | 114.3 | 0.083 | 2.11 | 5.897 | 0.12 | 3.05 | 8.452 | 0.203 | 5.16 | 14.028 | 0.237 | 6.02 | 16.237 |
| DN125 | 5’’ | 141.3 | 0.109 | 2.77 | 9.559 | 0.134 | 3.4 | 11.679 | 0.203 | 5.16 | 17.499 | 0.258 | 6.55 | 21.986 |
| DN150 | 6’’ | 168.28 | 0.109 | 2.77 | 11.42 | 0.134 | 3.4 | 13.964 | 0.216 | 5.49 | 22.262 | 0.28 | 7.11 | 28.545 |
| DN200 | 8’’ | 219.08 | 0.134 | 2.77 | 14.926 | 0.148 | 3.76 | 20.167 | 0.237 | 6.02 | 31.95 | 0.322 | 8.18 | 42.974 |
| DN250 | 10’’ | 273.05 | 0.156 | 3.4 | 22.838 | 0.165 | 4.19 | 28.052 | 0.237 | 6.02 | 40.043 | 0.365 | 9.27 | 60.911 |
| DN300 | 12’’ | 323.85 | 0.156 | 3.96 | 31.555 | 0.18 | 4.57 | 36.346 | 0.237 | 6.02 | 47.661 | 0.375 | 9.53 | 74.617 |
| DN350 | 14’’ | 355.6 | 0.156 | 3.96 | 34.687 | 0.188 | 4.78 | 41.772 | 0.258 | 6.55 | 56.951 | 0.437 | 11.1 | 95.255 |
| DN400 | 16’’ | 406.4 | 0.165 | 4.19 | 41.98 | 0.188 | 4.78 | 47.821 | 0.258 | 6.55 | 65.24 | 0.437 | 11.1 | 109.301 |
| DN450 | 18’’ | 457.2 | 0.165 | 4.19 | 47.394 | 0.203 | 5.16 | 58.103 | 0.322 | 8.18 | 91.494 | 0.563 | 14.3 | 157.767 |
| DN500 | 20’’ | 508 | 0.203 | 5.16 | 64.633 | 0.217 | 5.5 | 68.845 | 0.375 | 9.53 | 118.333 | 0.595 | 15.1 | 185.4 |
| DN550 | 22’’ | 558 | 0.203 | 5.16 | 71.06 | 0.217 | 5.5 | 75.695 | 0.375 | 9.53 | 130.203 | 0.626 | 15.9 | 214.709 |
| DN600 | 24’’ | 609.6 | 0.216 | 5.49 | 82.616 | 0.285 | 6.5 | 97.651 | 0.375 | 9.53 | 142.452 | 0.689 | 17.5 | 258.111 |
| DN700 | 28’’ | 711.2 | 0.216 | 5.49 | 96.51 | 0.322 | 8.18 | 143.25 | 0.5 | 12.7 | 220.975 | 0.689 | 17.5 | 302.401 |
| DN750 | 30’’ | 762 | 0.258 | 6.55 | 123.26 | 0.322 | 8.18 | 153.601 | 0.5 | 12.7 | 237.046 | 0.689 | 17.5 | 314.546 |
| DN800 | 32’’ | 812.8 | 0.322 | 8.18 | 163.952 | 0.5 | 12.7 | 253.117 | 0.689 | 17.5 | 346.691 | |||
| DN850 | 34’’ | 863.6 | 0.322 | 8.18 | 174.304 | 0.5 | 12.7 | 269.188 | 0.689 | 17.5 | 368.836 | |||
| DN900 | 36’’ | 914.4 | 0.322 | 8.18 | 184.655 | 0.5 | 12.7 | 285.259 | 0.748 | 19.1 | 425.967 | |||
| DN1000 | 40’’ | 1016 | 0.375 | 9.53 | 238.928 | 0.563 | 14.3 | 356.819 | 1.031 | 26.2 | 645.985 | |||
Industrial Fluid Transmission Stainless Steel Pipe Process Diagram
Steel Coil → Re inspection → Cutting → Molding → Automatic Welding → Inside weld bead reamove → Outside seam grinding → Online solution annealing → Online bright annealing → Online eddy current inspection → Sizing → Cut to length → End plain → Hydraulic or airtightness test → Polishing or Degreasing pickling → Inspection for finish product → Marking
304 316 Industrial Stainless Steel Pipe Production Workshop
Youfa SS Pipe Advantages
Youfa Stainless Steel Pipe Certificates
Industrial Fluid Transmission Stainless Steel Pipe FAQ
1.Q: What are Industrial Fluid Transmission Stainless Steel Pipes?
A: These are pipes made from stainless steel, designed specifically for transporting fluids in industrial applications. They are valued for their strength, corrosion resistance, and durability, making them suitable for use in harsh environments and with various types of fluids, including water, oil, chemicals, and gases.
2.Q: What types of fluids can these pipes transport?
A:They can handle a wide range of fluids, including water, oil, natural gas, chemicals, steam, and even aggressive or corrosive liquids. Their compatibility with different fluids depends on the grade of stainless steel used.
3.Q: In which industries are these pipes most commonly used?
A: Key industries include:
Oil and Gas: For pipelines and refinery applications.
Chemical Processing: For transporting corrosive chemicals.
4.Q: What are the key benefits of using stainless steel pipes for fluid transmission?
A: Corrosion Resistance: Prevents rust and degradation.
Durability: Long service life under harsh conditions.
Temperature Resistance: Performs well in both high and low temperatures.
Hygienic: Easy to clean, important for food, beverage, and pharmaceutical industries.
Strength: Handles high pressure and mechanical stress.
5.Q: What is the difference between seamless and welded stainless steel pipes?
A: Seamless Pipes: Made from a solid billet, offering higher strength and better pressure resistance, with no welded seam.
Welded Pipes: Made by welding a strip or plate of steel, which is more cost-effective and available in larger diameters, though with a seam.
6.Q: How do you select the right grade and type of stainless steel pipe for your application?
A: Consider the following factors:
Corrosiveness of Fluid: Higher grades like 316 are better for corrosive environments.
Temperature and Pressure Requirements: Ensure the pipe can handle the operational conditions.
Hygiene Requirements: For food, beverage, and pharmaceutical applications, choose pipes that are easy to clean and maintain.
Budget: While seamless pipes offer higher strength, welded pipes are more economical.
7.Q: How does the cost of stainless steel pipes compare to other materials?
A: Stainless steel pipes are generally more expensive than carbon steel or PVC pipes due to their superior properties, but they offer better longevity and resistance to corrosion, reducing long-term costs.
